MAHAVIR ISUZU
MU-X
MU-X
On Road Price: Lakhs*
Specifications Request on Road Price
| Model | mu-X | |
|---|---|---|
| Engine | ||
| Type | 4 Cylinder, Common Rail, VGS Turbo Intercooled Diesel | |
| Engine Displacement | 1898 cm3 (cc) | |
| Max Power | 120 kW (163 hp) @ 377 rad/s (3600 rpm) | |
| Max Torque | 360 Nm @ 209-262 rad/s (2000-2500 rpm) | |
| Cylinder head | ISUZU-patent special aluminium alloy with double-walled water jacketing | |
| Cylinder block | Cast iron upper with advanced anti-friction induction-hardened cylinder bores, cast alloy lower | |
| Valve train | Heavy-duty steel chain-driven dual overhead camshafts (DOHC), roller rockers, 4 valves per cylinder | |
| Fuel injection | Electronic high pressure common-rail diesel-direct injection (Ddi) | |
| Air induction | Intercooled Variable Geometry System (VGS) | |
| Pistons | Diamond-like carbon-coated pistons and injectors | |
| Emission level | Bharat Stage VI | |
| Transmission | ||
| Type | Automatic with Sequential Shift & Brake Shift Lock Electronically controlled with Adaptive Grade Logic & fuel-saving Lock-up Torque Converter | |
| 4x4 system | "Terrain Command” control with 'shift-on-the-fly' 2-high 4-high selection at up to 100 km/h | |
| Drivetrain system | Electronic Stability Control (ESC) & Traction Control System (TCS) | |
| Chassis | ||
| Frame | Separate, full-length heavy-duty ladder construction chassis | |
| Front suspension | Independent, Double wishbone, coil springs, gas shock absorbers, stabiliser bar | |
| Rear suspension | Penta-link coil suspension, gas shock absorbers, stabiliser bar | |
| Axles | ||
| Front | Independent. 4x4: fully floating with outer CV & inner double offset joints | |
| Tyre Type | Radial, Tubeless | |
| Rear | Rigid semi-floating banjo with hypoid final drive | |
| Steering | ||
| Type | Speed-sensitive variable capacity power-assisted rack & pinion system | |
| Adjustment | Tilt-adjustable steering wheel | |
| Steering Type | Hydraulic Power Assist with Tilt Adjustment | |
| Brakes | ||
| Type | Power- assisted via 266 mm (10.5 inch) servo unit 4 - Channel 4-Sensor Anti - Lock Brake System (ABS) with Electronic Brakeforce Distribution (EBD) & Emergency Brake Assist (EBA) | |
| Front | 300 mm dia ventilated front disc with twin-pot calipers | |
| Rear | 318 mm dia ventilated rear disc | |
| Wheels | ||
| Rim | 18 x 7J - 33, Diamond-cut Alloy | |
| Tyre | 255 / 60 R18 | |
| Full-size alloy spare wheel | ||
| Capacity | ||
| Seating | 7 persons | |
| Fuel Tank | 55 L capacity High Density Polyethylene (HDPE) tank | |
